19011 - Grip Hydraulic 2 X 300mm Vehicle Positioning Jack 680kg Capacity
Designed for safe and easy movement of vehicles without chassis contact. Unique foot pedal operation hydraulically squeezes arms together to lift up vehicle from the wheel.
- FEATURES
- All steel heavy duty construction.
- 4 heavy duty, nylon, swivel castor wheels for stability and 360° rotation.
- Safety locking pin prevents accidental vehicle drop while moving.
- 1 man, single hydraulic foot pedal operation.
-
Specifications:
- Working capacity 680kg.
- Wheel width capacity up to 304mm.
- Wheel diameter capacity 345 - 630mm.
- Roller width maximum 304mm.
- Castors size (H x W) 100 × 35mm.
- Weight (nett) each 18kg.
PLEASE NOTE: SAFTEY PROCEDURES
- Do NOT move vehicle unless locking pin is inserted.
- Mount tyre(wheel) in centre of roller.
- Do NOT use for towing between vehicles.
- Do NOT use on muddy or uneven surfaces.
